252kv High Voltage Oil Immersed Reverse Stand Outdoor Current Transformer

We goal to understand excellent disfigurement from the manufacturing and supply the top support to domestic and abroad clients wholeheartedly for Short Circuit Protection Current Transformer, Protection Electrical Current Transformer Center, Disposable 3 Ply Face Mask factory. We are willing to cooperate with business friends from at home and abroad and create a great future together. Facing the competition in the industry, we have always maintained the business philosophy of 'making first-class products and creating first-class enterprises', constantly innovating technology, updating equipment, and improving ourselves. We are always at the forefront of the industry, actively developing and innovating. We give full play to the important role of science and technology as the first productive force and attach great importance to scientific and technological progress and innovation.

Description

¨   50/60 Hz，Single Phase，AC Current Sensor

¨   Dynamic Range from 0.5 to 120Amps

¨   Meets IEC62053-21 class 1

¨   Meets IEC 60044-1 class 0.1 Phase error < 5'

¨   Immune to external AC magnetic field. Immune to DC current & DC magnetic field

¨   Very low temperature coefficient

¨   Meets UL class B (130℃) thermal insulation system

¨   Meets UL 94V-0

¨AC isolation resistance: 4KV for 60s

Application

•   Electricity meter

•   Recording

•   Power monitoring

•   Energy management

•   Alternative energy monitoring

ELECTRIC SPECIFICAITON AT 25℃
Model number	Turns Ration	Ipri4	Iout5	Iprimax6	Ioutmax7	RS	Accuracy Class3	RL8	Weight	Frequency range
		Amps	mA	Amps	mA	Ohms		Ohms	(g)	(Hz)
LO-ADC0001	1:2500	10	4	120	50		0.1	25		50-60

Note:

1.Output voltage is proportional to the derivative(di/dt)of the input current based on the Rogowski Coil principle.

2.All current and voltages assumed to be sinusoidal waveforms at Fr, the constant rated frequency in Hz, measured as RMS value.

3.Accuracy class per IEC60044-1Table 11.

4.Ipri=Rated primary current.

5.Iout=Rated secondary current.

6.Iprimax=Sensed max primary current.

7.Loutmax=Sensed max secondary current.

8.R_L=Terminating resistance. Varying terminating resistance increases or decreases output Voltage /Ampers according to following

equation R_L=Vout*Nsec/Ipri

Schematic diagram:

Dimensions:
