3000: 1 Split Core Current Transformer Clamp CT

As always, we will provide you with the best products at the best price, as well as technical moulding and finishing services at all times to meet your ever-changing needs for Round Zero Sequence Current Transformer factory, ZCT Zero phase current transformer, Current Transformer PCB CT. We will meet the requirements of our customers with high-quality products, favorable price-performance ratio and timely after-sales service. We take 'no pollution to the environment, no stealing of technology, no deception of customers, no vicious competition' as our developing code. We're confident that we are going to possess a vibrant prospect and to be distributed all over the world within the years to come. In the face of new historical opportunities and challenges, our company is full of confidence.

Description

 LO-SPCT-0750 Series split-core current transformer AC current from 5A to 200 AMPS passing through the center conductor. Split core CTs are designed for fast and easy installation. The split core design permits non-contact current measurements through magnetic field induction without requiring that the primary wire be taken offline and disconnected for CT installation. This method permits a safer, easy and portable current measurement. An internal precision burden resistor across the secondary winding of the CT provides a safe low voltage output and permits safe opening of the secondary

Application

• Data logging • Recording • Power monitoring

• Energy management • Alternative energy monitoring

• Cost allocation

Features

Rated Current 5A to 200A loads.

Rated output: 0.333VAC at rated current

Accuracy: ± 1% from 5% to 120% of rated current

Phase Angle: Less than 2 degrees at 50% of rated current

Maximum Primary Voltage: 5000VAC(Insulated Conductor)

Operating Temperature: -15C to 60C

Frequency Range: 50-400Hz

Leads: 4Feets(105cm), UL 1015, Twisted Pair, 0.34 mm2(22AWG)

CE recognized. RoHS Compliant

Output and leads can be customized

Specificaiton

Model	I.D.	Rated Amps	Output	Accuracy	SIZE(mm)
					A	B	C	D	E
LO-SPCT-0750	0.75"	5, 15, 30, 50, 70, 100, 150, 200	0.333V	1	51.6	54.1	16.6	19.1	18
	(19.1mm)
LO-SPCT-1250	1.25"	70, 100, 150, 200, 250, 300, 400, 600		1	82.3	85.3	26.4	32	32.3
	(31.8mm)
LO-SPCT-2000	2.00"	400, 600, 800, 1000, 1200		1	120	125	29.6	52.5	52
	(50.8mm)
LO-SPCT-3000	3.00" x 5.00"	1000, 1200, 1500,2000.3000		1	145	199	30.5	76	130
	(76.2mm x127mm)

Payment

1. We accept Western Union and T/T

2.30% deposit and 70% before shipping

3. No payment collection. We only can deliver goods after getting full payment.

Shipping

1. Products are shipped via UPS / DHL / EMS / HK EMS / FedEx / TNT and so on expresses (door to door).

2. We Provide Drop shipping Service.

3.5 days delivery upon receiving payment if the qty is lower than 1000PCS and it is not customized products.

4. In order to ensure you receive your order tax free upon import, we declare lower value.

5. Shipping via EMS. UPS. FedEx and TNT express usually takes 3~7days dependent on the destination country.

Thanks to the latest technology and training, the quality of our 3000: 1 Split Core Current Transformer Clamp CT and customer service is constantly improving. The rigorous attitude of product quality and the spirit of excellence, exquisite manufacturing technology have integrated into the blood of the enterprise from the beginning. We build a new business model, accelerate business transformation, and strive to become an advanced company with global competitiveness.

Hot Tags: clamp ct split core current transformer, China, manufacturers, customized, quotation, low price, made in China, Power Current Transformer, Split core AC Current Transformer, Compact Split Core Current Transformers, Round Zero Sequence Current Transformer factory, 50A Current Transformer, Residual Current Sensor
