LO-ZCT402 CBCT zero sequence current transformer



Introduction:

In the electrical systems always exists the possibility of having shutdowns due to over currents or short circuits produced by operation mistakes, ambient conditions, lack of maintenance or atmospheric  discharges. Ground fault it occurs when one of the system phases get on direct contact to ground or to any metallic part that is grounded. The ground fault has its origin on different ways but the more common are reduced insulation, physical damages to insulation system or excessive transient or steady-state voltage stresses on insulation.  These problems can be produced due to moisture, atmospheric contamination, insulation deterioration, mechanical stresses, etc. Although the situations mentioned before can be avoided following a good maintenance Schedule, always exists the latent risk of a fault, commonly during the installation or major maintenance to equipment.

Features :
• Frequency Range: 50-400Hz
• AC isolation resistance: 5.0KV for 60s
• Rigid housing case with UL® 94V-0 polycarbonate
• Safety standard: IEC61862
• Max. Operation voltage:  AC660V
• Thermal Insulation Class:  Class B
• Humidity:  Up to 95%RH (Non-condensing)


Mechanical Specificaitons

P/N	Main circuit Current (A)	Diameter(Φ) (mm)	Dimensions(mm)			Layout dimensions(mm)
			L	W	H	D1-D2	M
LO-ZCT102	0-100A	46	85	32	94	88.5-100.5	6
LO-ZCT202	0-250A	65	108	32	120	108.5-122	6
LO-ZCT302	0-315A	80	128	36	140	134-144	6
LO-ZCT402	0-630A	100	150	36	162	152-172	6
LO-ZCT502	0-1000A	120	172	36	184	177-197	6



ABSOLUTE MAXIMUM RATINGS
Operating free air temperature range	-40ºC to 85ºC
Storage temperature range	-20ºC to 85ºC





Zero sequence current transformer
