Clamp Type Current Sensor High Precision
The high-precision clamp current sensor adopts a unique double-layer shielding technology, featuring small size, high precision, good stability and strong anti-interference ability.
- Product Introduction
Wuxi Liou Electronics Co.,Ltd is one of the leading manufacturers and suppliers of clamp type current sensor high precision in China. Our factory offer high quality customized products made in China with low price. Welcome to contact us for quotation.
Description
Split core AC current sensors have different hole sizes and current ratings to suit any application. Split core models are perfect for retrofits. Output is fixed at the industry standard.
Application
• Data logging • Recording • Power monitoring
• Energy management • Alternative energy monitoring
• Cost allocation
Features
• High accuracy at 10–130% of rated current
• AC isolation resistance: 3KV for 60s
• Swing open for ease of installation
• Double secured latches per side and keying holes
• Rigid housing case with UL® 94V-0 durable plastic
• Safety standard: IEC/EN60044-1
• Nominal phase angle error and
Nominal linearity error: Conform IEC61869-2
ConformIEC60044-1
•Max.operation voltage: AC600V
Specification
Item | Specification |
Inputs | |
Frequency range 50-60Hz | |
Accuracy range 10-130% of rated current | |
Outputs | |
output at rated current 2mA-200mA | |
Environmental | |
Operation temperature range -10°C to +60°C (+14°F to +140°F) | |
Storage temperature range-20°C to +85°C (+4°F to +185°F) | |
Lead length70 ft black/white twisted pair wire leads-22 AWG | |
CertificationsRoHS | |
Mechanical Specification
Part Number | Description | A | B | C | D | E | ΦF | PrimaryRated Amper | Weight |
| (g) | |||||||||
LO-SP3010 | CT1:3000, 0.5% accuracy | 40.5 | 24.6 | 22 | 26 | 14.5 | 10 | 5, 15, 30,50, 75,80 | |
LO-SP3016 | CT1:3000, 0.5% accuracy | 44 | 27 | 29 | 31 | 19 | 16 | 50, 70, 100,120 | |
LO-SP3024 | CT1:3000, 0.5% accuracy | 75 | 46 | 45 | 35 | 19.5 | 24 | 100, 150,200, 300 | |
LO-SP3036 | CT 1:3000, 0.5% accuracy | 91.6 | 58 | 57.4 | 40.9 | 22.8 | 36 | 300, 400,500, 600 |
Installation
FAQ
1.Q:Is your price competitive?
A: Only good quality products we supply. Surely we will give you best factory price based on
superior product and service.
2.Q:How you arrange shipment?
A: By UPS / DHL / EMS / HK EMS / FedEx / TNT and so on.
3.Q:How is your goods quality?
A:We cooperated with many world class companied for many years,. our products received good response from our customers.
